Solar cable harness connector MTT-450
MTT-450
Description:
Solar cable harness connector MTT-435, also called four ports solar cable connector, used to establish a tap connection of 4 insulated conductors to a low voltage ABC (Aerial Bundled conductors) up to 1.5KV. Applied in solar cable harness
With this PV cable connector, end user no need to cut or peeling the cable jacket during installation, inner aluminum teeth will provide reliable electrical contact after installation. It maybe applied with different piercing connectors with branch size can be compatible with 15 mm diameter cables.
- Product code : MTT-450
- Branch cables, mm2 : 4 x 4-50
- Torque, N*m : 10
- Product detail
- Specification
- Video
- Our Advantages
- Inquiry
Key Features
- Easy and quick installation
- Up to 4 of branch cables application
- Water and dust resistant, IP-67 grade protection
- Additional gaskets holders prevents from water leakage
- Wide application of sizes of PV cables 4-50 mm2
- Double insulated cable also applicable
- Copper or aluminum branch cable application
- UV resistant thermoplastic, guarantee long period usage
- Optional supply with piercing connector ZOP-57, ZOP-395
- Application temperature – 30 °C up to +70 °C
SPECIFICATION
Solar cable harness connector MTT-435, also called four ports solar cable connector, used to establish a tap connection of 4 insulated conductors to a low voltage ABC (Aerial Bundled conductors) up to 1.5KV. Applied in solar cable harness
With this PV cable connector, end user no need to cut or peeling the cable jacket during installation, inner aluminum teeth will provide reliable electrical contact after installation. It maybe applied with different piercing connectors with branch size can be compatible with 15 mm diameter cables.
APPLICATION
This solar PV cable connector will make cable branching work more easier and safety because there will no need to cut or peel cable’s insulation.
Solar cable piercing connector passed the factory tests, like Dielectrical voltage underwater test, UV temperature aging test, electrical aging test and corrosion aging test which conform with European quality inspection standards EN 50483-4, and IEC 61238-1.
Jera provide the option of medium and large scale solar power plants, with bigger size of solar power cables, and connectors related, also our solar solution contains the necessary products for installation of solar power panels at the small scale facilities with PV inverter through PV solar power cable infrastructure, connectors, PV fuse holders, MC4 type spanners.
Welcome to contact us for more information about this Solar cable Insulation piercing connector price.
Manufacturing
Watch Our Factory Video
Technical specification
|
Product code |
Branch cables, mm2 |
Torque, N*m |
|
MTT-450 |
4 x 4-50 |
10 |
PRODUCT VIDEO
our advantages
- JERA LINE is a factory, that produces overhead and underground cable infrastructure.
Which transmits electricity and information,via
-Of f Grid Soar Plants.
– Fiber Optic Cable Networks.
- In following catalog we present PV Cable Harness System for Medium & Large Scale Off Grid Solar Plants.
- JERA is operating according to lS09001, all our products meet the criteria of key regional standards, EN50483-4,IEC-61238-1,NFC 33020,UL 94.
- Welcome to cooperate, our intention is committed to build reliable, long-term business relationships.
Factory picture
ss
Plastic molding workshop
CNC metals workshop
Press forming workshop
Mold processing workshop
Helical wire Forming workshop
Products Assembly workshop
TESTING FACILITY
Under water aging test
Electrical aging test
Temp & Humi cycling test
UV & temperature test
Tensile strength test
Fire resistance test
